Denso OSGR
Applications
- Bobcat A770 Diesel / 751G / S185 / S185 Kubota V2203TEB Diesel / S185 Kubota V2607 Diesel
- Bobcat 5450 2197cc Diesel (Kubota V2203) '14-on
- Bobcat S160 1999cc Diesel (Kubota V2003) '02-on
- Bobcat T2250 & T320 3769cc Diesel (Kubota V3800DI-T) '07-on
- S250 / S250 Kubota V3800 Diesel
- S300 Kubota V3300T Diesel & V3800 Diesel / S330
- 753 Loader Kubota V1903EB Diesel '99-'03
- 753G Kubota V1903EB Diesel '99-'99
- 763 / 763F / 763G / 763HF / 763HG / 773 Kubota V2203EB Diesel '99-'00
- S100 Kubota V1505 '07-'13
- S130 Kubota V2203 & V2403 '02-'13
- S150 Kubota V2203 & V2403 '03-'13
- S160 Kubota V2003 & V2203 Diesel '03-'07
- S160 Kubota V2607 Diesel '08-'13
- S175 Kubota V2203EB Diesel '01-'08
- S175 Kubota V2403 Diesel '09-'13
- S205 Kubota V2403 Diesel '04-'07
- S205 Kubota V2607 Diesel '08-'13
- S220 Kubota V3300DI Diesel '04-'07
- S220 Kubota V3800 Diesel '08-'10
- S220 Turbo Kubota V3300-T Diesel '04-'14
- S510 Kubota V2203MDI & V2403MDI Diesel '13-'13
- S530 Kubota V2403MDI Diesel '13-'13
- S550 Kubota V2607DIT Diesel '13-'13
- S570 Kubota V2607DIT Diesel '13-'13
- S590 Kubota V2607DIT Diesel '13-'13
- S630 & S650 Kubota V3307 Diesel '09-'13
- S750 Kubota 85HP Tier III '11-'13
- S770 & S850 Kubota V3800 Diesel '11-'13
- T300 Turbo Kubota V3300DI Diesel '08-'13
- T2250 Kubota V3300DIT Diesel '08-'13
| Voltage | 12V |
| Polarity | Both |
| Power | 2kW |
Starter motor type terminology explained:
- OSGR – Off Set Gear Reduction (larger motor is offset, solenoid acts directly on drive).
- PMGR – Permanent Magnet Gear Reduction (planetary gearbox usually on drive axis).
- WFGR – Wound Field Gear Reduction.
It is strongly advised that PMGR units are not used in conjunction with a bulkhead mounted solenoid, by linking the B+ and ignition trigger terminal of our starter motor. This can cause the pinion to hang in mesh after the engine fires. It will cause unnecessary noise and wear to the ring gear, and will shorten the life of the starter motor's clutch.
We would advise that the slimline Hitachi or Axial types should only be favoured over a Denso type due to space constraints / form factor.
WOSP is 100% OE based. However for many of our more price sensitive lines such as our classic range, we use a remanufactured OE Denso starter motor. This still offers far better quality than a new aftermarket or imitation piece. You will see the type noted with a suffix *r to denote this.
