Portable articulated borescope supplied with 70mm TFT colour display. Mini waterproof (IP67) camera with integral light (Ø6mm) mounted on 800mm flexible 2-way articulated probe. Using an attached dial, the camera head angle can be changed by up to 350˚ without having to remove camera from inspection area. Using 8GB micro SD card (supplied), up to 9hrs of video and 20,000 still images can be recorded. Videos and still images can be downloaded to a PC via USB data cable (supplied). CMOS camera with six LED probe light and a focus distance of 20-50mm for fine control of light output and clear pictures. Potential applications; automobile maintenance, engine inspection, pipe line exploration etc. Powered by 4 x AA batteries (not included).
• Portable articulated borescope supplied with 70mm TFT colour display.
• Mini waterproof (IP67) camera with integral light (Ø6mm) mounted on 800mm flexible 2-way articulated probe.
• Using an attached dial, the camera head angle can be changed by up to 350˚ without having to remove camera from inspection area.
• Using 8GB micro SD card (supplied), up to 9hrs of video and 20,000 still images can be recorded.
• Videos and still images can be downloaded to a PC via USB data cable (supplied).
• CMOS camera with six LED probe light and a focus distance of 20-50mm for fine control of light output and clear pictures.
• Potential applications; automobile maintenance, engine inspection, pipe line exploration etc.
• Powered by 4 x AA batteries (not included).
Specifications
| Model No |
VS8233A |
| Accessories: |
8GB Micro SD Card, USB Data Cable |
| Adjustable Light Control: |
No |
| AV Out: |
No |
| Brand: |
Sealey |
| Camera Probe Length: |
800mm |
| Camera: |
Ø6mm |
| Mirror Flip/Rotate Function: |
Yes |
| Nett Weight: |
373g |
| Optional Probes: |
No |
| Pod Length: |
20mm |
| Power Source: |
4 x AA Batteries (not included) |
| Record Function (Video + Still): |
Yes |
| Screen Resolution: |
640 x 480 pixels (Colour) |
| Screen Size: |
70mm |
| SD Memory Slot: |
Yes |
| USB Connection: |
Yes |
| Viewing Angle: |
60° |
